Monogram Systems
COMPONENT MAINTENANCE MANUAL
BASIC PN 15900
38-31-09
Page 711
Feb 23/04
E. Liquid Level Transmitter Assembly, PN 13503-106 or 13503-110 (refer to Figure 5)
(1) List of Materials
NOTE: Equivalent substitutes may be used.
ITEM IDENTIFICATION SOURCE
Sealant No. 404 & Grade C per
MIL-S-22473
Loctite Company
300 N. Mountain Road
Newington, CT 06111
Safety Wire MS20995C20 per
MS35540
Commercially available
Twine .06 Wide Nylon per MIL-
T-713
Commercially available
(2) Procedure
(a) Assemble sensor PC board (125 or 125A) to light driver PC board (130
or 130A) by aligning guide pins and pressing assemblies together.
(b) Install grommets (100) on banana plugs of sensor PC board (125 or
125A) with spongy side of grommet adjacent to PC board.
(c) Assemble mounting plate (80) on sensor PC board (125 or 125A) with
tab on base indexed in hole in PC board. Use screws (85), nylon washers
(90), washers (95 or 95A), ground wire lug (105), spacers (110 and 115)
and threaded supports (20) to secure mounting plate (80) to PC boards.
Use Loctite, Grade C, sealant on threads of screws (85).
(d) Install ground wire assembly into the harness on light driver PC board
(130 or 130A) using lacing twine on wire bundle.
(e) Connect plug (120) of light driver PC board (130 or 130A) wire bundle
to receptacle (70) of case (5). Turn retaining ring to lock plug to
receptacle.
