Monogram Systems
COMPONENT MAINTENANCE MANUAL
BASIC PN 15900
- ITEM NOT ILLUSTRATED
* SHIPPED LOOSE WITH FINAL ASSEMBLY
38-31-09
Page 1020
Feb 23/04
FIG.
ITEM
PART NUMBER
AIRLINE
PART NO.
NOMENCLATURE
1 2 3 4 5 6 7
USED
ON
CODE
UNITS
PER
ASSY
1
ATTACHING PARTS
115 NAS679C08M . NUT 8
R 120 AN960C8L . WASHER (REPLD BY ITEM -120A) 8
R -120A NAS1149CN816R . WASHER (REPLS ITEM 120) 8
* * *
125 15900-155 . SOLENOID VALVE ASSY A,B 1
-125A 15900-199 . SOLENOID VALVE ASSY C 1
ATTACHING PARTS
130 NAS679C3M . NUT 4
R 135 AN960C10L . WASHER (REPLD BY ITEM -135A) 4
R -135A NAS1149C0332R . WASHER (REPLS ITEM 135) 4
* * *
140 66103-3 . . PIN, CONTACT (V00779) 2
145 207359-1 . . CONNECTOR, RECEPTACLE
(V00779)
1
150 2520 . . CONNECTOR, STRAIN RELIEF
(V59730)
1
155 0701-195 . . ADAPTER, HOSE (V06090) 2
160 15900-156 . . BRACKET, SOLENOID VALVE
MOUNTING
2
165 15900-154 . . SOLENOID VALVE 1
185 4687 . FITTING, VENT 1
ATTACHING PARTS
190 NAS679C06M . NUT 4
R 195 AN960C6L . WASHER (REPLD BY ITEM -195A) 4
R -195A NAS1149CN616R . WASHER (REPLS ITEM 195) 4
* * *
200 4313 . GASKET, VENT 1
205 MS24566-1B . PULLEY 1
210 MS9463-08 . CLEVIS PIN 2
215 MS24665-148 . COTTER PIN 2
R 220 AN960C10L . WASHER (REPLD BY ITEM -220A) 2
R -220A NAS1149C0332R . WASHER (REPLS ITEM 220) 2
225 4631-84 . BRACKET, PULLEY 1
