Monogram Systems
COMPONENT MAINTENANCE MANUAL
BASIC PN 15900
- ITEM NOT ILLUSTRATED
* SHIPPED LOOSE WITH FINAL ASSEMBLY
38-31-09
Page 1021
Feb 23/04
FIG.
ITEM
PART NUMBER
AIRLINE
PART NO.
NOMENCLATURE
1 2 3 4 5 6 7
USED
ON
CODE
UNITS
PER
ASSY
1
ATTACHING PARTS
230 NAS679C08M . NUT 4
R 235 AN960C8L . WASHER (REPLD BY ITEM -235A) 4
R -235A NAS1149CN816R . WASHER (REPLS ITEM 235) 4
240 MS9463-08 . CLEVIS PIN 1
245 MS24665-148 . COTTER PIN 2
R 250 AN960C10L . WASHER (REPLD BY ITEM -250A) 2
R -250A NAS1149C0332R . WASHER (REPLS ITEM 250) 2
255 MS24566-1B . PULLEY 2
* * *
260 MS9463-09 . CLEVIS PIN 1
275 99-022-094-0500 . PIN, ROLL (V40720) 1
305 4631-82 . BRACKET, PULLEY A,B 1
-305A 4631-124 . BRACKET, PULLEY C 1
ATTACHING PARTS
R 310 AN960C10L . WASHER (REPLD BY ITEM -310A) 4
R -310A NAS1149C0332R . WASHER (REPLS ITEM 310) 4
315 NAS679C3M . NUT 4
* * *
R 320 4650-24 . DRAIN VALVE ASSY
(SEE IPL FIGURE 3 FOR DETAILS)
AA 1
R -320A 4650-31 . DRAIN VALVE ASSY
(SEE IPL FIGURE 3 FOR DETAILS)
AB 1
ATTACHING PARTS
325 NAS679C06M . NUT 9
R 330 AN960C6L . WASHER (REPLD BY ITEM -330A) 9
R -330A NAS1149CN616R . WASHER (REPLS ITEM 330) 9
* * *
335 4670-1 . GASKET, DRAIN VALVE 1
340 C10DK3 . CLAMP (V81872)
(TRUE PN C10DK-3)
3
