Monogram Systems
COMPONENT MAINTENANCE MANUAL
BASIC PN 15900
- ITEM NOT ILLUSTRATED
* SHIPPED LOOSE WITH FINAL ASSEMBLY
38-31-09
Page 1022
Feb 23/04
FIG.
ITEM
PART NUMBER
AIRLINE
PART NO.
NOMENCLATURE
1 2 3 4 5 6 7
USED
ON
CODE
UNITS
PER
ASSY
1
ATTACHING PARTS
345 NAS679C3M . NUT 2
347 NAS679C08M . NUT 1
R 350 AN960C10L . WASHER (REPLD BY ITEM -350A) 2
R -350A NAS1149C0332R . WASHER (REPLS ITEM 350) 2
R 352 AN960C8L . WASHER (REPLD BY ITEM -352A) 1
R -352A NAS1149CN816R . WASHER (REPLS ITEM 352) 1
354 3752-21 . SPACER 2
***
355 4631-73 . BRACKET, CONNECTOR 1
ATTACHING PARTS
360 NAS679C08M . NUT 2
R 365 AN960C8L . WASHER (REPLD BY ITEM -365A) 2
R -365A MS1149CN816R . WASHER (REPLS ITEM 365) 2
* * *
370 MS51957-15 . SCREW 4
R 375 AN960C4L . WASHER (REPLD BY ITEM -375A) 4
R -375A NAS1149CN416R . WASHER (REPLS ITEM 375) 4
380 NAS1291C04M . NUT 4
385 11059-79 . TIMER ASSY
(SEE IPL FIGURE 4 FOR DETAILS)
1
ATTACHING PARTS
390 MS51957-28 . SCREW 4
R 395 AN960C6L . WASHER (REPLD BY ITEM -395A) 4
R -395A NAS1149CN616R . WASHER (REPLS ITEM 395) 4
* * *
400 17000-298 . GASKET 1
405 4631-72 . BRACKET, TIMER 1
ATTACHING PARTS
410 NAS679C08M . NUT 2
R 415 AN960C8L . WASHER (REPLD BY ITEM –415A) 2
R -415A NAS1149CN816R . WASHER (REPLS ITEM 415) 2
* * *
