Monogram Systems
COMPONENT MAINTENANCE MANUAL
BASIC PN 15900
- ITEM NOT ILLUSTRATED
* SHIPPED LOOSE WITH FINAL ASSEMBLY
38-31-09
Page 1023
Feb 23/04
FIG.
ITEM
PART NUMBER
AIRLINE
PART NO.
NOMENCLATURE
1 2 3 4 5 6 7
USED
ON
CODE
UNITS
PER
ASSY
1
420 4631-81 . BRACKET, TIE DOWN 3
ATTACHING PARTS
425 NAS679C08M . NUT 6
R 430 AN960C8L . WASHER (REPLD BY ITEM –430A) 6
R -430A NAS1149CN816R . WASHER (REPLS ITEM 430) 6
* * *
435 2435-14-18 . STRAP, GROUNDING 1
440 4812-25 . STUD, GROUNDING 1
ATTACHING PARTS
R 445 AN960C10L . WASHER (REPLD BY ITEM –445A) 4
R -445A NAS1149C0332R . WASHER (REPLS ITEM 445) 4
450 MS35338-138 . WASHER 1
455 NAS679C3M . NUT 1
* * *
R 460 13503-106 . TRANSMITTER, LIQUID LEVEL
(REPLD BY ITEM –460A)
(SEE IPL FIGURE 5 FOR DETAILS)
AC 1
R -460A 13503-110 . TRANSMITTER, LIQUID LEVEL
(REPLS ITEM 460)
(SEE IPL FIGURE 5 FOR DETAILS)
AD 1
ATTACHING PARTS
465 MS51958-60 . SCREW 3
470 MS35338-138 . WASHER 3
R 475 AN960C10L . WASHER (REPLD BY ITEM –475A) 3
R -475A NAS1149C0332R . WASHER (REPLS ITEM 475) 3
* * *
480 13451-036 . GASKET 1
485 13451-033 . PLATE, MOUNTING 1
ATTACHING PARTS
490 MS24693C269 . SCREW 4
* * *
