Monogram Systems
COMPONENT MAINTENANCE MANUAL
BASIC PN 15900
- ITEM NOT ILLUSTRATED
* SHIPPED LOOSE WITH FINAL ASSEMBLY
38-31-09
Page 1023.1
Feb 23/04
FIG.
ITEM
PART NUMBER
AIRLINE
PART NO.
NOMENCLATURE
1 2 3 4 5 6 7
USED
ON
CODE
UNITS
PER
ASSY
1
495 2-034S604-70 . O-RING (V02697) 1
500 MS29513-343* . O-RING (V02697) 2
510 4520-2* . SEAT ASSY A 1
-510A 4521-11* . SEAT ASSY B,C 1
515 AN507C632R5 . . SCREW A 5
-515A MS24693C-46 . . SCREW B,C 5
-517 860832 . . INSERT B,C 5
520 4631-88 . . HINGE A 1
525 2393-21 . . BUMPER A 2
-527 4521-11-2 . . BLOCK B,C 1
530 4514 . . SEAT A 1
-530A 4521-11-1 . . SEAT ASSY M/F (4806-22-10) B,C 1
535 15900-180 . TANK AND TOP ASSY A 1
-535A 15900-186 . TANK AND TOP ASSY B 1
-535B 15900-194 . TANK AND TOP ASSY C 1
540 13505-005 . . CONTACT 4
545 MS35649-264 . . NUT 1
550 CK05BX102K . . CAPACITOR 1
555 PT8-6R . . TERMINAL (V06383) 1
560 1488-6 . . LUG (V83330) 2
565 MS35650-304 . . NUT 1
R 570 AN960C10L . . WASHER (REPLD BY ITEM -570A) 2
R -570A NAS1149C0332R . . WASHER (REPLS ITEM 570) 2
575 P18-10R . . TERMINAL (V06383) 1
-580 TY24M . CABLE TIE (V59730) B,C AR
585 15900-226 . BRACKET, SUPPORT B 1
