COMPONENT MAINTENANCE MANUAL
BASIC PN 15900
FIG.
ITEM
PART NUMBER
AIRLINE
PART NO.
NOMENCLATURE
1 2 3 4 5 6 7
USED
ON
CODE
UNITS
PER
ASSY
- ITEM NOT ILLUSTRATED
38-31-09
Page 1025
Feb 23/04
2
-1 3511-007 MOTOR-PUMP-FILTER ASSY
(SEE IPL FIG. 1 FOR NHA)
A RF
-1A
3512-007 MOTOR-PUMP-FILTER ASSY
(SEE IPL FIG. 1 FOR NHA)
B RF
5 2333-7 . DECAL 1
10 3516-013 . MOTOR AND ADAPTER ASSY A 1
-10A
3516-019 . MOTOR AND ADAPTER ASSY B 1
. ATTACHING PARTS
15 NAS679C3M . NUT 1
R 20 AN960C10L . WASHER (REPLD BY ITEM –20A) 6
R -20A NAS1149C0332R . WASHER (REPLS ITEM 20) 6
25 4812-25 . STUD 1
30 NAS501-3H4A . BOLT 3
***
35 15900-151 . . MOTOR ASSY A 1
-35A
15900-152 . . MOTOR ASSY B 1
ATTACHING PARTS
40 MS51957-27 . . SCREW 4
***
45 2333-7 . . NAMEPLATE 1
50 3516-005 . . PLATE, ADAPTER 1
55 025-050-012 . SEAL (V27695) 2
60 3515-003 . BASKET, FILTER 1
ATTACHING PARTS
65 NAS679C08M . NUT 1
R 70 AN960C8L . WASHER (REPLD BY ITEM –70A) 1
R -70A NAS1149CN816R . WASHER (REPLS ITEM 70) 1
***
75 4812-94-13 . PLATE, IMPELLER HOUSING 1
ATTACHING PARTS
80 MS51957-53 . SCREW 6
85 NAS620C8 . WASHER 12
90 NAS1291C08M . NUT 6
***
