Monogram Systems
COMPONENT MAINTENANCE MANUAL
BASIC PN 15900
FIG.
ITEM
PART NUMBER
AIRLINE
PART NO.
NOMENCLATURE
1 2 3 4 5 6 7
USED
ON
CODE
UNITS
PER
ASSY
- ITEM NOT ILLUSTRATED
* SHIPPED LOOSE WITH FINAL ASSEMBLY 38-31-09
Page 1026
May 17/02
2
95 MS16624-4025 . RING, RETAINING 1
100 340121020 . WASHER, THRUST (V86928) AR
105 16006-006 . IMPELLER 1
110 4812-31 . WASHER, THRUST AR
115 4812-105 . HOUSING, IMPELLER 1
120 4812-174-11 . DRIVE SHAFT ASSY 1
125 MS24665-87 . PIN, COTTER 1
130 4812-107 . WASHER 2
135 3516-011 . SPRAY NOZZLE 1
140 3516-009 . HOUSING, ANTISIPHON 1
ATTACHING PARTS
145 MS51957-49 . SCREW 2
150 NAS620C8 . WASHER 4
155 NAS1291C08M . NUT 2
***
160 16006-031 . GASKET 1
165 16202-020 . FLAPPER 1
170 NAS1291C08M . NUT 3
175 AN960C8 . WASHER 3
180 16006-033 . GASKET 1
185 16006-032 . WASHER, RETENTION 1
190 14100-019 . TUBE, INLET 1
195 3514-003 . FRAME ASSY 1
ATTACHING PARTS
200 MS24693C30 . SCREW 5
205 NAS620C6 . WASHER 5
210 NAS1291C06M . NUT 5
***
215 3516-001 . PLATE, MOUNTING 1
220 3509-1 . GASKET, MOUNTING PLATE * 1
