Monogram Systems
COMPONENT MAINTENANCE MANUAL
BASIC PN 15900
38-31-09
Page 702
Feb 23/04
2. Assembly Instructions
A. Toilet Assembly, PN 15900-013/-017/-020 (refer to IPL Figure 1)
(1) List of Materials
NOTE: Equivalent substitutes may be used for listed items
ITEM IDENTIFICATION SOURCE
Adhesive No. 1357 Minnesota Mining &
Manufacturing. Co.
Adhesive Division
St. Paul, MN 55101
(2) Procedures
(a) Install O-ring (500) on tank and top assembly (535, -535A or –535B).
(b) Assemble and install seat assembly (510 or –510A) as follows:
1 Install hinge (520) with screws (515).
2 Install bumpers (525) to seat (530 or –530A).
(c) Install transmitter mounting plate (485), new gasket (480) and new O-ring
(495) on tank and top assembly (535) with screws (490).
(d) Install liquid level transmitter (460 or –460A) with screws (465) and
washers (470 and 475 or –475A).
(e) Install ground strap (435) and grounding stud (440) with nut (455) and
washers (445 or –445A and 450).
(f) Install tie down brackets (420) with nuts (425) and washers (430 or
–430A).
(g) Install timer bracket (405) with nuts (410) and washers (415 or –415A).
(h) Install timer assembly (385) and new gasket (400) to timer bracket (405)
with screws (390) and washers (395 or –395A).
(i) Install timer connector to bracket (355) with screws (370), washers (375 or
–375A) and nuts (380).
(j) Install connector bracket (355) with nuts (360) and washers (365 or –
365A).
