(k) Install clamps (340) with spacers (354), nuts (345 and 347) and washers
(350 or –350A and 352 or –352A).
(l) Install drain valve assembly (320 or –320A) support bracket (585) and
gasket (335) with nuts (325) and washers (330 or -330A).
(m) Install pulley bracket (305 or –305A) with washers (310 or –310A) and
nuts (315).
(n) Install pulleys (255) with cotter pins (245), clevis pins (240 and 260),
washers (250 or –250A) and roll pin (275).
(o) Install pulley bracket (225) with nuts (230) and washers (235 or –235A).
(p) Install pulley (205) with cotter pin (215), clevis pin (210) and washer (220
or –220A).
(q) Install vent fitting (185) and gasket (200) with nuts (190) and washers
(195 or –195A).
(r) If removed during disassembly, install contact pins (140), connectors (145
and 150), adaptor hose (155) and mounting brackets (160) on solenoid
valve (165).
(s) Install solenoid valve assembly (125) with nuts (130) and washers (135 or
–135A).
(t) Install motor-pump-filter assembly (110 or –110A), secure with washers
(120 or –120A) and nuts (115).
(u) Install fill line hose (100) with clamps (105).
(v) Position bowl gasket (75) on the tank and top assembly.
(w) Install restrictor (70).
(x) Install bowl assembly (55) with washers (65 or –65A) and nuts (60).
(y) Connect grounding strap (50).
(z) Install flush hose (40) and secure with clamps (45).
(aa) If removed at disassembly, replace decal (5).
