Monport 40W User Manual

4
No.
Label
Pins
Use
1
DC
—
DC 12-48V power Supply
2
—
—
USB-C
3
Reset
2
Reset
4
Probe
2
Z axis height automatic detection
5
Run
2
Continue the process
6
Holo
2
Process the process
7
X+
3
X Axis Limit Switch
8
X-
3
X Axis Limit Switch
9
Y+
3
Y Axis Limit Switch
10
Y-
3
Y Axis Limit Switch
11
Z+
3
Z Axis Limit Switch
12
Z-
3
Z Axis Limit Switch
13
Offline plug
8
Offline control
14
DC 24V
2
DC output/input 24v
15
PWM/5V
3
5V Output Signals
16
PWM/12V
3
12V Output Signals
17
PWM
2
5V Output Signals
18
12V
2
5V Temp. Controller Signal
19
12V
2
5V Temp. Controller Signal
20
Z/motor
4
Z Axis Driver Signal
21
Y2/motor
4
Y2 Axis Driver Signal
22
Y1/motor
4
Y1 Axis Driver Signal
23
X/motor
4
X Axis Driver Signal
24
SPN
2
Trouble-locating
25
DC 48V
2
DC output 48V
26
DC 24V
2
DC output 24V
