Monroe Electronics 287a - Section 5 GLOSSARY

Section 5
GLOSSARY
  
Blank voltage (Main Menu Startup screen)
 or 
Polarity indicator (positive or negative voltage)
 or 
Scroll up or down list
A
Refers to Automatic test
Adjust
Displays while plate voltage is being adjusted to 1050 volts
Auto Seq
See The Set-up Menu (Page 6)
AutoShtDwn
See The Set-up Menu (Page 6)
Bal
See The Set-up Menu (Page 6)
Bal dur
See The Set-up Menu (Page 6)
C
Celsius temperature
Chrg
Indicates that the plate is being charged
ClrData
See The Set-up Menu (Page 6)
Decay
Indicates that the plate voltage is decaying
Delay
Pause between auto tests
Enter
When displayed, press ENTER to view or modify the present option
Decay Failed
Voltage did not decay to 100V within 200sec; or discharge failed to
reach +1000V
Exit
See The Set-up Menu (Page 6)
Fac. Deflt
See The Set-up Menu (Page 6)
M
Refers to Manual test
MDA
Average times for Manual Decay tests
MemUsed
Shows percentage of Automatic and Manual memory currently in
use
Min
Minutes (see AutoShtDwn and The Set-up Menu (Page 6)
Mn
Min voltage in balance tests
Mx
Max voltage in balance tests
MnB
Balance results for Manual test n where n is test number
Mn+ or Mn
Decay time for Manual test n where n is test number (1-0)
MnTH
Temperature and Humidity data for Manual decay test n
NAD
Average Decay times for automatic sequence N
NBa
Balance results for automatic sequence N
NnD+ or NnD
Decay times for automatic test number n (1-3) in test sequence N (1-
0)
NTH
Temperature and Humidity for automatic sequence N
Null
Results from holding any primary key too long — reverts to main
display
Off
If ON/OFF key is released while Off is displayed, the unit will be shut
off
ON=EXIT
Press ‘ON’ key to exit Set-up menu
RH
Relative Humidity in percent
RvwData
See The Set-up Menu (Page 6)
Sec or s
Time in seconds
Set-Up
Release key to enter Set-Up mode
Tst dly
See The Set-up Menu (Page 6)
V
Volts
Ver
Firmware version
Zero
Indicates that the instrument is being autozeroed
