Section 5
GLOSSARY
Blank voltage (Main Menu Startup screen)
or
Polarity indicator (positive or negative voltage)
or Scroll up or down list
A Refers to Automatic test
Auto Seq See the Set-up Menu (Page 6)
AutoShtDwn See the Set-up Menu (Page 6)
Bal See the Set-up Menu (Page 6)
Bal dur See the Set-up Menu (Page 6)
C Celsius temperature
Charge Indicates that the plate is being charged
ClrData See the Set-up Menu (Page 6)
Decay Indicates that the plate voltage is decaying
Delay Pause between auto tests
Enter When displayed, press ENTER to view or modify the present option
Decay Failed Voltage did not decay to 100V within 200sec; or discharge failed to
reach +1000V
Exit See the Set-up Menu (Page 6)
Fac. Default See the Set-up Menu (Page 6)
M Refers to Manual test
MDA Average times for Manual Decay tests
MemUsed Shows percentage of Automatic and Manual memory currently in
use
Min Minutes (see AutoShtDwn and The Set-up Menu (Page 6)
Mn Min voltage in balance tests
Mx Max voltage in balance tests
MnB
Balance results for Manual test n where n is test number
Mn+ or Mn
Decay time for Manual test n where n is test number (1-0)
MnTH
Temperature and Humidity data for Manual decay test n
NAD
Average Decay times for automatic sequence N
NBa
Balance results for automatic sequence N
NnD+ or NnD
Decay times for automatic test number n (1-3) in test sequence N (1-
0)
NTH
Temperature and Humidity for automatic sequence N
Null Results from holding any primary key too long — reverts to main
display
Off If ON/OFF key is released while Off is displayed, the unit will be shut
off
ON=EXIT Press ‘ON’ key to exit Set-up menu
RH Relative Humidity in percent
RvwData See the Set-up Menu (page 6)
Sec or s Time in seconds
Set-Up Release key to enter Set-Up mode
Tst dly See the Set-up Menu (Page 6)
V Volts
Ver Firmware version
Zeroing Indicates that the instrument is being autozeroed
Unable to charge
Indicates the meter is unable to charge above start value
8
