The system may not be installed in a place where flammable gas could escape.
3.5 CONNECTING THE EXHAUST AIR HOSE
The air conditioner must be vented to the outside so that the exhaust air coming from the unit and
containing waste heat and moisture can escape from the room.
Do not replace or lengthen the exhaust hose, as this may damage the unit.
Step 1: Connect the hose connector to one end of the exhaust hose.
Step 2: Connect the adapter for the window kit to the other end of the exhaust air hose.
Step 3: Adjust the adjustable window kit by the length of your window. Connect the exhaust air
hose to the window kit.
Step 4: Close the window to secure the kit in place. The window kit must be held firmly in place. If
necessary, secure the window kit with additional means. It is advisable to seal the space between
the adapter and the window sides for maximum efficiency.
Step 5: Connect the hose connector to the unit’s exhaust air outlet.
