Engine controls
All yachts are fitted with the a single lever
'TX'
type throttle and gear change lever.
N=Neutral
F=Forward
Gear
R=Reverse
Gear
T=Throttle
Increase
Gear selection
Forward is selected by pushing the lever
forward, the further forward it is pushing the
higher the engine revs.
Reverse is selected by pulling lever aft and
again, the further aft it is pulled, the higher
the engine revs.
To increase engine revs without selecting a
gear, press and hold the gear disengage
button (1) then move lever to
forward/reverse. Disengage button (1) will
pop out when passing lever through neutral.
/
Warning: Gear selection will re-engage
when lever is returned to neutral
Lever
Disengage button
TX Lever
Engine stop mechanisms
Diesel engines are stopped by preventing the fuel being injected into the cylinders.
This is achieved using a cable operated control marked
'STOP'
To stop, pull and
hold the control knob until the engine has stopped. When the engine has stopped,
push the control knob back to the
'RUN'
position. Then switch off the engine
ignition.
This control also operates a cold start, by pulling out once before trying to start
engine.
/
If it is not pushed all the way in, the engine will not start.
f
On engines fitted with mechanical stop
systems,
do not turn the key to the
'off-position
whilst
* the engine is running. This can seriously damage the charging
system,
particularly the
alternator.
Page 4.6
Issue 3
