Figure 6. Summarizing the TRZ Configuration Menus in a HART Communicator
MAIN MENU
1 DEVICE SETUP
2 TEMP
3 LRV
4 URV
5 I OUT
6 % RANGE
7 DATA LOGGER
DEVICE SETUP
1 INPUT SETUP
2 OUTPUT SETUP
3 DEVICE INFORMATION
4 DIAG/SERVICE
INPUT SETUP
1 SIGNAL CONDITION
2 SENSOR TYPE
3 LRV
4 URV
5 DAMP
6 UNIT
7 WIRE NO.
OUTPUT SETUP
1 UNDER LIM
2 OVER LIM
3 SENSOR ERROR
DEVICE INFORMATION
1 DISTRIBUTOR
2 MODEL
3 DEV ID
4 TAG
5 DATE
6 WRITE PROTECT NONE
7 DESCRIPTOR
8 MESSAGE
9 FINAL ASMBLY NUM
REVISION #S
HART OUTPUT
DIAG/SERVICE
1 LOOP TEST
3 SENSOR TRIM
SENSOR TRIM
1 FACTORY TRIM
2 ONE POINT TRIM
3 TWO POINT TRIM
4 TEMP
HART OUTPUT
1 POLL ADDR
2 # PREAMBLES
Key
% RANGE = Output Current in % of Span
# PREAMBLES = Number of Preamble Characters
DAMP = Damping Value
DEV ID = Device Identification
DIAG = Diagnostic
I OUT = Output Current
LRV = Lower Range Value
MAX VALUE = Maximum Process Value
MIN VALUE = Minimum Process Value
OFFS = Offset
POLL ADDR = Polling Address
URV = Upper Range Value
WIRE NO = Number of Input Wires
DATA LOGGER
1 MAX PROCESS VALUE
2 MIN PROCESS VALUE
3 RESET MIN/MAX
2 D/A TRIM
6 S.GAIN
5 S. OFF
