TRZ
Configuring a TRZ
The TRZ can be configured with either a HART Com-
municator or a PC and Moore Industries’ TRZ Intelli-
gent PC Configuration Software.
One of the benefits of the TRZ transmitter is that
there are no internal or external controls to adjust or
settings to change. All operating parameters are set
using either a HART Communicator or the Configura-
tion software. Once these software settings are
made, they are “downloaded” to the transmitter in the
form of a Configuration File and stored in the non-
volatile unit memory and on your PC hard drive or
diskette. The transmitter communicates with the PC
through a HART modem connection to the PC’s
serial (COM) port. The transmitter and the HART
Communicator can communicate at any termination
point on the loop.
You can configure the TRZ with either a standard
HART Communicator or our PC software. Figure 2
shows the hookup for configuring the TRZ with a PC.
Figure 3 shows the configuration hookup with a HART
Communicator. Refer to Table 2 for the specifications
for the equipment shown in these figures.
The following section of the manual contains instruc-
tions for configuring the TRZ with or without the use of
a HART Communicator:
• Installing the TRZ Configuration Software
(if necessary) page 8
• Saving the TRZ Configuration Files
(if necessary) page 10
• Setting Output, page 13, 17-18
• Configuring the Device Information,
page 13
• Using the Loop Test function, page 14
• Trimming the Input, page 14
• Displaying and Resetting the Minimum and
Maximum Process Values, page 15
