16 The Interface Solution Experts
TRZ
Figure 7. Generic Menu Overview
ONLINE GENERIC
1 DEVICE SETUP
2 PV
3 PV AO
4 PV LRV
5 URV
DEVICE SETUP
1 PROCESS VARIABLES
2 DIAG/SERVICE
3 BASIC SETUP
4 DETAILED SETUP
5 REVIEW
PROCESS VARIABLE
1 SNSR
2 AI %
3 A01 DISPLAY
DIAG/SERVICE
1 TEST DEVICE
2 LOOP TEST
3 CALIBRATION
4 D/A TRIM
BASIC SETUP
1 TAG
2 PV UNIT
3 RANGE VALUES
4 DEVICE INFORMATION
5 PVXFER FNCTN
6 PV DAMP
DETAILED SETUP
1 SENSORS
2 SIGNAL CONDITION
3 OUTPUT CONDITION
4 DEVICE INFORMATION
CALIBRATION
1 APPLY VALUES
2 ENTER VALUES
RANGE VALUES
1 PVLRV
2 URV
3 PVLSL
4 USL
DEVICE INFORMATION
1 DISTRIBUTOR
2 MODEL
3 DEV ID
4 TAG
5 DATE
SENSORS
1 PV
2 PV SNSR
3 SENSOR INFORMATION
SIGNAL CONDITION
1 SNSR DAMP
2 URV
3 AI LRV
4 AI XFER FNCTN
5 AI % RANGE
OUTPUT CONDITION
1 ANALOG OUTPUT
2 HART OUTPUT
ANALOG OUTPUT
1 AO1
2 AO ALRM TRIP
3 LOOP TEST
4 D/A TRIM
5 SCALED D/A TRIM
HART OUTPUT
1 POLL ADDR
2 NUM REG PREAMS
3 BURST MODE
4 BURST OPTION
Key
AI % = % of Analog Input
AO = Analog Output
DAMP = Damping Value
DEV ID = Device Identification
DIAG = Diagnostic
D/A TRIM = Trim Digital/Analog
LRV = Lower Range Value
LSL = Lower Sensor Level
NUM REG PREAMS = Number of Preamble Characters
POLL ADDR = Polling Address
PV = Process Variable
SNSR = Sensor
URV = Upper Range Value
USL = Upper Sensor Level
XFER FNCTN = Transfer Function
ENTER VALUES
1 PVLRV
2 URV
3 PVUSL
4 PVLSL
To Next Page
