NOTE:Theremayalreadybea22pinconnectortothe

radio.Usetheexistingoneanddiscardtheonesup

pliedinthekit.

76.Backouttheconnectorwirelockingtabfromtheradio

harnessconnector.

77.Insertthecameraharnesswiresintotheradioharness

connectorasfollows:

a.Signalwire(DG/BR)cavity3

b.Returnwire(DG/OR)cavity4

c.Shieldwire(DG/WT)cavity5

78.Positiontheradiototheinstrumentpanel.

79.ConnecttheAM/FMantenna(2).

80.Connecttheelectricalconnector(1).

81.Connectthesatellite/navigationantenna(3).

82.Ifequipped,connecttheUSBconnectors(4).

83.Installtheradio(2)mountingfasteners(1).

Jun30,2011K6861197
