59.Positiontheswitchbankassembly(1)andfirmlypress
intoinstrumentpaneltosecurethesnapretainers.
60.Positionthefloorconsolesidecloseoutpanel(1)and
firmlypressintoplacesecuringthetwosnapretain
ersthatsecurethecloseoutpaneltotheinstrument
panel,andthefivesnapretainersthatsecuretheclose
outpaneltothefloorconsole.
61.ConnecttheLED/Lampwiringharness(2)tothestor
agebin(1).
62.Connectthe12Vignitionpoweroutletwiringharness
(3)totherearofthestoragebin(1).
63.Positionthestoragebin(1)andfirmlypushintoplace
securingthetwosnapretainerstothefloorconsole
sidecloseoutpanel.
64.Installthescrews(4)securingthestoragebin(1)to
theconsole.
Nov16,2010K6861117
