K6862043
3/11/14
1. Loosen one (1) 10mm bolt and disconnect
negative battery cable
2
NOTE: Vehicle with tailgate liner shown.
The tailgate liner and tailgate cover are
removed and installed as one piece.
2. Open the tailgate.
3. If equipped with tailgate liner (2), remove screws (1)
and remove the tailgate cover.
4. Using a grease pencil or equivalent, mark the
location of the actuator rods (2) at the latch control.
5. Disconnect the actuator rods from the latch control.
