For sufficient leveling and air circulating
in the lower rear section of the
appliance, the bottom feet may need
to be adjusted. You can adjust them
manually by hand or by using a suitable
tool.
To allow the doors to self-close, tilt the
top backwards by 0.4" - 0.6"(10-15mm).
Leveling of appliance
Adjustable
bottom feet
Front roller Rear roller
0.4"~0.6"(10-15mm)
Adjustable
bottom feet
Before you use the appliance, you have to
install the handles provided in the fridge
chamber.
The longer one is fridge door handle, the
shorter one is freezer door handle.
Please follow procedures below to install
and reverse the handle.
Installing the handles
Take out the screw hole covers on the
doors, install the handle supports(C).
Place the handle (A) on the door by
supports (C), then fasten the screws (B)
with 3mm Allen wrench (provided in
plastic bag).
7
