Subassembly Component List – BASIC-ONE™ (continued)
VP-20041-14 COVER-L ABS LEFT SIDE COVER 1.000
3/16 X 35 X 11.438-BLACK
MMI20030-3 BASIC 1 TOP PLATE 1.000
17 X 22 ALUM PLATE
KAISER
HANDLE PUSH BAR MMI20046 HANDLE PUSH BAR 1.000
BASIC ONE -120 WALL X 1
X STEEL TUBING
MMI20042 #2 BRKT ASS #2 BRKT ASSY 1.000
BASIC ONE
MMI20043 LAT BRKT LAT BRACKET ASSY 1.000
MMI20031-4R 1.7 X 20 CLAMP BARS RIGHT 1.000
BASIC ONE
MMI20031-4L 1.7 X 20 CLAMP BARS LEFT 1.000
BASIC ONE
AV-SM/LG PB ASSY SMALL PILLOW BLOCK ASSY 1.000
MMI20044 TREN/LAT BR TREN/LAT BRACKET ASSY 1.000
GASKET-20045 MOTOR GASKET 20045 1.000
1/16 ABS PLASTIC GASKET
7.75 X 7.75 W/ 4 HOLES
MMI20047-1" RISER 1" RISER BLOCK 1.000
5.75 X 5.75 X 1"
MCM-9688K281 PLUG-NYLON SNAP IN UNVENTE 2.000
13/16 ID X 1 1/32 HEAD
MAG-MAX30A12335 CURL MAX30A120335AOA1-00-000 1.000
DC Tilt Motor, 8000N-CURLY
CORD 120mm stroke * TREND
WASHERS-20046-2 1/4 X 1.0 X 3.75 6.000
PUSH BAR WASHER FOR HANDLE
MCM-SEAL TAPE 1/2" MCM-9477K21-VALUE-SEAL 0.060
EXPANDED PIPE GASKET TAPE
MCM-74125K73 SNAP IN DUST TIGHT GRIP 1.000
FITTING 5/8 HOLE
MMI20041-DECK COVER BASIC DECK COVER FRONT & B 1.000
20041-11- & 20041-12
