Morgan PLUS FOUR - Page 22

19
DRIVER INFORMATION PANEL - OIL LEVEL
It is recommended that an oil level check is carried out periodically.
To activate an oil level measurement, the vehicle should be:
1. Parked on a level surface. 2. Park or Neutral gears selected. 3. The engine should be running at normal operating temperature.
WARNING Do not scroll through Driver Information menus while driving the vehicle.
Engine Oil Level
PRESS the right stalk button to cycle through to
the Engine Oil Level. The reading displayed defaults
to the last measurement.
Oil Level Measurement
With the Oil Level Menu selected, HOLD the right
stalk button to summon a new measurement. An
hourglass icon appears while a measurement is active.
0
2
1
0
Int
3/4
3/4
0
2
1
0
Int
No Measurement Available
If the above icon is displayed, either one or more
of the conditions listed above are not met, or
there is a problem with obtaining a measurement.
0
2
1
0
Int
