Morso 7670 - Page 9

9
8
CLEARANCE REQUIREMENTS ALCOVE INSTALLATION
DOUBLEWALL CONNECTOR
USA CANADA
A.
B.
C.
D.
E.
F.
G.
H.
W.
D.
G.
15’’
1’’
N/A
21’’
7’’
N/A
33,5’’
70.5”
N/A
32’’
33,5’’
381 mm.
25 mm.
N/A
533 mm.
178 mm.
N/A
851 mm.
1791 mm.
N/A
813 mm.
851 mm.
SIDEWALL TO UNIT
BACKWALL TO UNIT
CORNERWALL TO UNIT
SIDEWALL TO CONNECTOR
BACKWALL TO CONNECTOR
CORNERWALL TO CONNECTOR
UNIT TO CEILING
FLOOR TO CEILING
MINIMUM ALCOVE WIDTH
MAXIMUM ALCOVE DEPTH
ALCOVE CEILING ABOVE STOVE TOP
CLEARANCE REQUIREMENTS STANDARD RESIDENTIAL INSTALLATION
INTEGRAL REAR AND BOTTOM SHIELDS
TOP OR REAR VENT
SINGLE OR DOUBLEWALL CONNECTOR
USA CANADA
A.
B.
C.
D.
E.
F.
G.
H.
15’’
1’’
2,5’’
21’’
7’’
8,5’’
47’’
84’’
381 mm.
25 mm.
64 mm.
533 mm.
178 mm.
216 mm.
1194 mm.
2134 mm.
SIDEWALL TO UNIT
BACKWALL TO UNIT
CORNERWALL TO UNIT
SIDEWALL TO CONNECTOR
BACKWALL TO CONNECTOR
CORNERWALL TO CONNECTOR
UNIT TO CEILING
FLOOR TO CEILING
FLOOR PROTECTOR MUST BE NON-COMBUSTIBLE
MATERIAL, IT MUST EXTEND BENEATH HEATER AND TO
THE FRONT/SIDES/REAR AS INDICATED.
LE PROTECTEUR DE PLANCHER DOIT ÈNTRE MATÉRIAL
INCOMBUSTIBLE, IL DOIT S'ÉTENDI EN DESSOUS DE
L'APPAREIL ET AU DEVANT, CÔTE ET À L'AARIÈRE DEL
L'APPAREIL COM INDIQUE.
