I

I

MASKINFABRIK

HARALDSVEJ21

DK-8900

RANDERS

TLF.+

45864351

55

FAX.

+ 45 86 43 51 00

Instructions

manual

MORS0 Mitring machine

Model

F


F-1


F-2

I

Beware

of

the

extreme

sharp knives

Service

F-4

REGULATION

OF

DRAW

BAR

As

the

knives

are

worn

it

will

be

necessary

to

adjust

the

draw

bar

(1).

The

following

procedure

is

used:

1.

The

foot pedal

(2) is

pressed

home

and

locked

by

means

of the

height stop (3).

2.

Loosen

nut

(4).

3.

Nut (5) is

screwed

so

much upwards that

the

knife

edge goes about

4-6

mm

under

the

upper

side

of the

bottom knives.

5.

Fasten

nut (4)

against

the

draw

bow

(6).

ADJUSTMENT

OF

FORWARD

MOVEMENT

When

you

have changed used knives

it

might

be

necessary

to

adjust

the

forward movement.

1. The

knife

block unit

is

placed

in the

front

position

with

handle

(7) (on the


it

is

shown

in the

rear

position).

The

fences

(8) + (9)

must

be

adjusted

on

standard

(45 )

position

and be

fastened.

2.

Loosen

nut

(10).

3.

Bushing

(11)

is

turned with

a

spanner until

the

front

point

of the

knives goes

a

little

bit

between

the

fences

(8) + (9) , but the

knives must

not

touch

the

fences.

4.

Fasten

nut

(10) while

holding

the

bushing

(11)

in the

adjusted

position

by

means

of

the

spanner.

The

position

of the

knives

is

checked

by

moving

the

knife

block

down

slowly.

If the

fences

(8) + (9) are not

touched,

put a

moulding

in the

machine

and cut it. If the

moulding

does

not

split

on the

front

edge

the

adjustment

is

correct.

MORS0

F

-9503

F-4/gb1

23
