210 Watt (160 Watt @12V6) x 4
AS200.4
CEA-2006-A SPECIFICATIONS
POWER RATING: 200 Watt per channel @ 4 Ohm < 1% THD+N
SN RATIO: >86 dBA (reference: 1 Watt into 4 Ohm)
MOS SPECIFICATIONS (Tcase = 25 °C / 4 Ohm stereo / 0.2V input level @ 14.4 Volt if not otherwise specified)
TARGET POWERs: 200 Watt per channel @ 4 Ohm
320 Watt per channel @ 2 Ohm
640 Watt BTL mode @ 4 Ohm
950 Watt BTL mode @ 2 Ohm (*)
EFFECTIVE POWERs: 87.9 A (η = 66.3 %) @ 4 Ohm / ST mode / 1% THD / 1KHz
326 Watt (252 Watt @12V6) x 4 151.2 A (η = 60.0 %) @ 2 Ohm / ST mode / 1% THD / 1KHz
652 Watt (504 Watt @12V6) x 2 151.2 A (η = 60.0 %) @ 4 Ohm / BTL mode / 1% THD / 1KHz
THD @ 4 Ohm / ST mode: < 0.03 % (1KHz / 90% Power rating ref)
Absolute maximum operation supply voltage range: 10 V ÷ 16 V
Bandwidth (-3dB ÷ 1 Watt): < 5 Hz ÷ 150 KHz
Input sensitivity (Power rating ref): 0.2 V ÷ 5 V
Input impedance @ 1 KHz (STEREO input): 11 KOhm
S/N ratio (AP filter 10 Hz - 22 KHz ) - Power rating ref: 109 dB (“A” weighted)
Xover functions: HIGH Pass & LOW Pass (BAND Pass allowed)
(20 ÷ 175Hz) & (50 ÷ 300Hz)
Filter slope - Filter “Q”: 12 dB/oct - 0.7 (Stereo & Mono)
Thermal cutoff Threshold: 88 °C (±5°C)
ProSPEED
®
Fan Controller Threshold: 55 °C (±5°C)
Load drive limitations (*): 1 Ohm / 2 Ohm (Stereo / Bridged)
Suggested fuse: 150 A (Internal)
Size: 590x200x50 mm
Weight: 5,8 Kg
(*) VERY IMPORTANT NOTE - READ CAREFULLY
4 Ohm ST or 8 Ohm BTL – CONTINUOUS SINEWAVE SIGNAL – pure resistive load or speaker load
2 Ohm ST or 4 Ohm BTL – MUSICAL SIGNAL – pure resistive load or speaker load
1 Ohm ST or 2 Ohm BTL – MUSICAL SIGNAL – speaker load only
MOS di IVAN MOSCONI
Via La Villa, loc. Ghilardino – 61034 Fossombrone (PU)
Tel. +39.0721.1830601 – Tel/Fax +39.0721.728570
info@mosconi-system.it - www.mosconi-system.it
4-channel AB class amplifier available in Silver and White finishing
