X100L Load Bank
4
2) Specifications
Blower 120VAC, single phase, 60Hz powered from control
Control power 120VAC, single phase, 60 Hz
Rating Continuous duty
Power factor 1.0
Load elements
Each circuit is connected in delta.
The kW at each step is subject to a manufacturing tolerance of ±5%.
Enclosure
powder coat, Blue: PPG PC
Touch up paint is Pantone 280-c color. Plastikote custom color universal blend.
Air inlet and outlet are covered by metal screens.
Heat is discharged horizontally.
Environmental 8 x 240V, 420CFM fans to bring outside air into the load bank.
a) X100L Load Bank
3Ø
Customer Input
1Ø
Customer Input
Jumper
By Customer
To Next Page
