10 User Guide - v11
HD Interceptor Camera with IR (IR275)
The HD Interceptor Camera variant with IR illumination is a ruggedized aluminum encased
PTZ HD camera. It includes an IR light source providing greater low and night- time
illumination.
250mm / 9.84in
420mm / 16.54in Pan Sweep
422mm / 16.61in
View on Side FaceView on Front Face
View on Bottom Face
380mm / 14.96in
11.0mm /
0.43in
4 x Diameter 9mm
102mm / 4.02in PCD
Diameter
125mm / 4.92in
Mounting Base
Diameter
270mm /
10.63in
Tilt Sweep
Figure 4: HD Interceptor Camera variant with IR and white illumination
Dimensions
• 250mm / 9.84 in (w) x 380mm / 14.96 in (h)
• Pan sweep:
• 420mm / 16.54 in (w) x 422mm / 16.61 in (h)
Weight
• 8.25 Kg (18 lbs)
2 Hardware Description HD Interceptor Camera - Specialized Range
