Radio Control Buttons and Display
Power
1. Channel [1–20]
2. Call Tone [Off, 1–20]
3. Roger Tone [On/Off]
4. Dual Channel Monitor
5. Keypad Tone [On/Off]
6. Easy Pairing
7. Speaker Volume [0–7]
8. Battery Indicator [3
Battery Levels]
9. Status [Transmit]
10. Status [Receive]
11. Scan Indicator
12. Keypad Lock
13. iVOX [Off, L1, L2, L3]
VOX [Off, L1, L2, L3]
14. Sub-Code [0–121]
2
3
4
5
1
6
7
8
9
11
13
10
12
14
Menu/
Lock
Screen
Speaker
Antenna
Micro-USB
Charging Port
Easy Pairing Button
Microphone
Call Tone
Scroll
Scan/Monitor
PTT Button
Accessory Port
Space for Personalization
Stickers
