Motorola DP1400 Series

1-8 Introduction: Specifications
Conforms to:
ETSI TS 102 361 (Parts 1, 2 & 3) - ETSI DMR Standard
ETSI EN 300 086 - ETSI RF Specifications (Analog)
ETSI EN 300 113 - ETSI RF Specifications (Digital)
1999/5/EC (R&TTE - Radio and Telecommunications Terminal Equipment)
2002/95/EC (RohS - Banned Substances)
2002/96/EC (WEEE - Waste Electrical and Electronic Equipment)
94/62/EC (Packaging and Packaging Waste)
Radio meets applicable regulatory requirements.
Transmitter DP1400
Frequencies VHF: 136 – 174 MHz
UHF: 403 – 470MHz
Channel Spacing 12.5 kHz/ 20 kHz/ 25 kHz
Frequency Stability (-30°C to
+60°C, +25 °C Ref)
+/-0.5 ppm
Power Output (Low Power) 1 W
Power Output (High Power) VHF: 5 W
UHF: 4 W
Modulation Limiting +/-2.5 kHz @ 12.5 kHz
± 4.0 kHz @ 20 kHz
+/-5.0 kHz @ 25 kHz
FM Hum and Noise -40 dB @ 12.5 kHz
-45 dB @ 20 kHz/ 25 kHz
Conducted / Radiated Emission -36 dBm < 1 GHz
-30 dBm > 1 GHz
Adjacent Channel Power 60 dB @ 12.5 kHz
70 dB @ 20/25 kHz
Audio Response TIA603D
Audio Distortion 3%(typical)
FM Modulation 12.5 kHz: 11K0F3E
25 kHz: 16K0F3E
4FSK Digital Modulation 12.5 kHz Data: 7K60F1D & 7K60FXD
12.5 kHz Voice: 7K60F1E & 7K60FXE
Combination of 12.5 kHz Data and Voice: 7K60F1W
Digital Vocoder Type AMBE+2™
Digital Protocol ETSI-TS102361-1
ETSI-TS102361-2
ETSI-TS102361-3
