Motorola DP1400 Series

2-4 Test Equipment and Service Aids: Portable Programming Cable
Table 2-3. Pin Configuration of Portable Programming Cable with TTR
CONNECTION
P1 P2 P3 Function
11 VCC(5V)
22
DATA-
33
DATA+
4
BNC Center Pin TTR
5
4 BNC Shell GROUND
