2-6 Test Equipment and Service Aids: Portable Test Cable
Table 2-4. Pin Configuration of Portable Test Cable
CONNECTION
P1 P2 Function
1 1,5 GROUND
2 7,24 EXTERNAL MIC
3 16 EXTERNAL SPEAKER -
4
17 EXTERNAL SPEKAER +
