Disassembly/Reassembly Procedures: Disassembling and Reassembling the Radio — General 5-5
5.5 Disassembling and Reassembling the Radio — General
When disassembling and reassembling the radio, it is important to pay particular attention to the
snaps and tabs, and how parts align with each other.
The following tools are required for disassembling the radio:
• TORX™ T6 screwdriver
• Chassis and Knob Opener (p/n: 6686533Z01)
• Flat square tip plastic tweezer
The following item and tools are required for reassembling the radio:
• Grease (1185937A01)
• TORX™ T6 screwdriver
• Flat square tip plastic tweezer
If a unit requires further testing or service than is customarily performed at the basic level, please
send the radio to a Motorola Service Center.
To assure the safety and regulatory compliance of the radio must be repaired
only at Motorola service facilities. Please call Motorola at 800-422-4210 for the
address and contact information of your nearest service center
