Disassembly/Reassembly Procedures: Radio Disassembly – Detailed 5-7
4. Pry off the volume and channel selector knobs from their shafts using the knob remover/
chassis opener tool (Motorola p/n: 6686533Z01).
Figure 5-2. Channel Selector and Volume Knob Removal
NOTE
Both knobs slide on and off. However, they are supposed to fit very tightly on their shafts.
Volume Control Knob
Channel Selector
Knob
