Motorola DP1400 Series

Disassembly/Reassembly Procedures: Radio Reassembly - Detailed 5-31
4. Place the option board with flex into the front kit.
5. Use TORX screw driver with T6 bit to fasten the 2 screws to the front housing.
6. Gently insert the flex into the fully opened actuator.
Option Board
Front Kit
