Disassembly/Reassembly Procedures: Radio Exploded Mechanical View and Parts Lists 5-37
Table 5-3. Exploded View Part List
Item Description Part Number
1 Antenna Refer VHF Model Chart
Table 1.4.1 VHF Model
Chart and UHF Model
Chart Table 1.4.2 UHF
Model Chart
2 Knob, Frequency 3680530Z02
3 Knob, Volume 3680529Z01
4 Product Number Label 33012039019
5 Front Cover Kit PMLN6345_
5.1 Nameplate 33012026001
5.2 Front Housing Assembly Part of item No.5 (Front
Cover Kit)
5.3 Dust Cover, Audio Jack 15012242001
5.4 Dust Cover, Micro USB 38012042001
5.5 Felt, Microphone 3586621Z04
5.6 Boot, Microphone 0780608V01
5.7 Microphone Assembly 0104055J51
5.8 Felt, Speaker 35012094001
5.9 Speaker Assembly 0104055J50
5.10 Speaker Retainer 4286620Z01
5.11 Screw, Speaker Retainer 0386434Z02
6 Back Cover Kit See Table 5-6 Back Cover
Kit Part Numbers Back
Cover Kits
6.1 Main O-Ring 3286431Z05
6.2 Poron Pad 75012247001
6.3 Screw, Main Board 0304726J05
6.4 Top Control Seal 32012232001
6.5 Main PCB Assembly Part of item No.6 (Back
Cover Kit)
6.6 Thermal Pad (thin) 7515526H01
6.7 Thermal Pad (thick) 75012205001
6.8 Battery Contact Seal 3286435Z01
6.9 Chassis Assembly 0104056J93
7 Shroud Assembly, Audio Jack 01012093001
