3 Installation For GP68
3.1.2 Remove Radios Chassis
a. Remove the antenna. The antenna screws off counter-
clockwise (Figure 3-3).
b. Remove the two screws at the back of the chassis
(Figure 3-3).
c. Slide the chassis downwards a little and lift it away from
the front housing (Figure 3-3).
NOTE
Please note that the flat ribbon cable
still connects the controller board and
the RF board. Be careful not to strain
this cable while separating the chassis
from the front housing.
Figure 3-3 Remove Radio Chassis
