8-24 Model Chart and Test Specifications
Transmitter
Specification 800 MHz
Frequency Range:
Transmit:
Talkaround:
806-821 MHz
851-866 MHz
Power Output: 2.5W @ (806-821 MHz) 2W @(851-866 MHz)
Channel Spacing: 25 kHz
Freq. Stability:
(-30°C to +60°C)
±2.5 ppm
Spurs/Harmonics: -47 dBc
Adjacent Channel Power: -70dBc @ 25 KHz
Audio Response:
(from 6 dB/oct. Pre-Emphasis, 300
to 3000Hz)
+1 to -3 dB
Audio Distortion:
@ 1000 Hz, 60%
Rated Max. Dev.
3% Typical
Modulation Limiting: ±5 kHz @ 806-821 MHz
FM Noise: -40 dB
Receiver
Specification 800 MHz
Frequency Range: 851-866 MHz
Sensitivity
12dB EIA SINAD:
-0.35 µV
Channel Spacing: 25 kHz
Intermodulation ETS: 70 dB
Adjacent Channel Selectivity ETS: 70 dB
Spur Rejection: 70 dB
Rated Audio: 0.5 W
Audio Distortion@Rated Audio: 3% Typical
Audio Response (0.3-3 kHz): +1 to -3 dB
Hum and Noise: -45dBm
Conducted Spurious Emmission: -57dBm
Specifications subject to change without notice. All electrical specifications and methods refer to EIA/TIA 603 standards.
Professional Series radios meet or exceed requirements of MIL STD 810 C, D, E.
