8/03
Parts List
HT90 Series
REF.
NO. PART NO. DESCRIPTION
REF.
NO. PART NO. DESCRIPTION
1 0105950G05 Assembly
, Front Cover; Standard
2 ---- Not used
3
3205472P09 Gasket, Seal
4
3305153J01 Label, Nameplate
5
1105932J01 Adhesive, Felt
6
3505152J01 Felt, Speaker
7
5005181E02 Speaker, (LS401)
8
7505182J01 Pad, Microphone Boot
9
---- Microphone (MK401) P/O RPX4654A
10
---- Bracket, Microphone P/O RPX4654A
11 ---- Boot, Microphone P/O RPX4654A
12
0300138651 Screw
, Phillips: 2-56 x 5⁄32˝
13
4205670D01 Clamp, Speaker
14 ---- Connector (P401) P/O RPX4654A
15
3205332K01 Seal
16
4182093A07 Spring, Actuator; coiled
17
4505177J01 Actuator, Push-to-Talk
18 0705175J01 Bracket, Actuator
19
4105176J01 Spring, Actuator
20
2205390M01 Pin, Retainer
21
3205082E13 Gasket, “O” Ring
22
0305466C02 Screw, Special; 4-40 x 0.140˝
23
4605170J01 Stud, Latch
24
3205082E14 Gasket, “O” Ring
25
4105172J01 Spring, Latch
26 5505150L01 Latch, Pawl
27
0405171J01 Washer, Teflon
28 ---- Not used
29 ---- Assembly, Housing; includes items
36, 37, 38, 39 & 40
0105954G94 Standard
or
0105954G95 Silverized
30 0300120621 Screw, Phillips; 4-40 x 1⁄4˝
31
0484345A06 Washer, Seal
32 ---- Label, FCC Identification, not field replaceable
33
----
Label, Frequency; not field replaceable
34
4210219A25 Retainer, E-Clip
35
6505214E01 Fuse (F501)
36 ---- Contact, Strap
37 ---- Contact, Positive
38 ---- Contact, Negative
39 ---- Bushing, Strap
40
---- Gasket, “O” Ring
*Items 36, 37, 38, & 40 are not field
replaceable; order applicable Housing
Assembly (item 2).
41 ---- Not used
42
0305887J01 Screw, Slotted; 4-40 x 3⁄16˝
44 0105953G48 PTT Switch (S202)
45
0705162J01 Bracket, PTT Switch
46
0305887J01 Screw, Slotted; 4-40 x 3⁄16˝
47
4305936J01 Bushing, Shoulder
48
3905567L02 Contact
49
0400008406 Lockwasher
50
0300138651 Screw, Phillips; 2-56 x 1⁄8˝
51
4305209J01 Sleeve
52 ---- Battery (see page 90)
53 ---- Not used
54A
4005120E03 Switch, Frequency; T
oggle (S201)
54B
3205082E17 Seal, “O” Ring
55
0205050E05 Nut, Spanner
56
2905658K01 Lug
56A ---- Lockwasher, Internal Tooth (p/o item 78)
57
0105956H97 Switch, Volume/On-Off (R202/S204)
58
3905195J02 Contact
59 ---- Plate, Retainer
60
---- Bushing
61
---- Panel, Control
**Items 59, 60, and 61 are not field
repairable; order Assembly 0105956H87
62
0105956H99 Switch, PL/Squelch Control
‘63
0105950G12 Jack, Speaker (J02) (S203-R201)
64
0405662K01 Washer, Insulating
65
3205082E15 Seal, “O” Ring
66
0205050E07 Nut, Spanner
67 ---- Not used
68 3205082E38 Seal, “O” Ring
69
0205629L02 Nut, Hex
70
3205933J02 Seal, Switch
71
3205082E11 Seal, “O” Ring
72
3805216J02 Plug, Seal
73
3205082E12 Seal, “O” Ring
74
4305206J01 Sleeve
75 6405208J01 Plate, Pressure
76 Escutcheon, Graphic; for
1305181J01 Basic Carrier Squelch Models
or
1305181J02 Universal, Carrier Squelch Models
or
1305181J09 Basic, PL Squelch Models
or
1305181J10 Universal, PL Squelch Models
77
3205082E28 Seal, “O” Ring
78
0900855268 Connector, Antenna (J203) BNC
79
RPX4630A Connector
, Universal (J201)
79A
3805216J01 Plug, Seal (Basic Models)
80
0205050E01 Nut, Spanner
81
0305662D17 Screw, Captive
82
0310129A24 Screw, Slotted; Nylon
83 ---- Not used
84 ---- Not used
85
3205217J01 Seal, Cap
86
0383174C02 Screw, Set
87
3605207J03 Knob, Volume and Squelch
88 ---- Not used
89
0405171J02 Washer, Nylon; Black
90
0282653D07 Nut, Spanner
91 0400009777 Lockwasher, No. 4
93 ---- Not used
94
1405135P01 Insulator, Mic.
97
8405878L02 Circuit Board, Printed (see Detail “A”)
Cancelled Product HT90: Aftermarket support
criteria has been met for spare parts. Items may
no longer be available.
