Motorola MT 2000 Manual

U.S. Military Spec 810C U.S. Military Spec 810D U.S. Military Spec 810E
Standard Method Procedure Method Procedure Method Procedure
Low Pressure 500.1 I 500.2 II 500.3 II
High Temperature 501.1 I 501.2 I (Cat. A1), II 501.3 I (Cat. A1), II
Low Temperature 502.1 I 502.2 I (Cat. C1), II 502.3 I (Cat. C1), II
Temperature Shock 503.1 I 503.2 I (Cat. A1, C1) 503.3 I (Cat. A1, C1)
Solar Radiation 505.1 I 505.2 I 505.3 I
Rain 506.1 I,II 506.2 II,II 506.3 I,II
Humidity 507.1 II 507.2 II, III 507.3 II, III
Salt Fog 509.1 I 509.2 I 509.3 I
Dust 510.1 I 510.2 I 510.3 I
Vibration 514.2 VII, VIII, X 514.3 I (Cat. 8) 514.4 I (Cat. 8)
Shock 516.2 I, II, V 516.3 I, IV 516.4 I, IV
Frequency Range: 136-174 MHz 403-470 MHz 450-520 MHz 806-825 MHz
851-870 MHz
Channel Spacing: 12.5/25/30 kHz 12.5/25 kHz 12.5/25 kHz 25 kHz
FM Hum & Noise:
@ 12.5 kHz: –40 dB –40 dB –40 dB
@ 25 or 30 kHz –45 dB –45 dB –45 dB –45 dB
(Companion Receiver Method)
Audio Distortion: 3% 3% 3% 3%
Spurious & Harmonics: –66 dBW –66 dBW –66 dBW –46 dBW
Frequency Stability:
(–30 to +60º C; 25º C ref.)
(821-824 MHz Capable): ± .0002% ± .0002% ± .0002% ± .0002%
FCC ID: AZ489FT3768 AZ489FT4781 AZ489FT4780 AZ489FT5747
Emission 25 kHz: 16K0F3E 16K0F3E 16K0F3E 16K0F3E
Designators: 20K0F2D 16K0F1D 20K0F2D 16K0F1E
20K0F1E 15K0F2D 20K0F1E 20K0F1E
20K0F1E 15K0F2D
16K0F1D
14K0F3E
14K0F1D
12.5 kHz: 11K0F3E 11K0F3E 11K0F3E N/A
11K0F2D 11K0F2D
Audio Response: +1, –3 dB +1, –3 dB +1, –3 dB +1, –3 dB
(from a 6 dB/octave
pre-emphasis 300 to 3000 Hz)
General Model Number Channels Bandsplit RF Power Output Display/Keypad
VHF Models H01KDD9AA4_N 48 136-174 MHz 1 to 5 Watts Top 6 Character/None
H01KDH9AA7_N 160 136-174 MHz 1 to 5 Watts Front 14 Character/15 Button
UHF Models H01RDD9AA4_N 48 403-470 MHz 1 to 4 Watts Top 6 Character/None
H01RDH9AA7_N 160 403-170 MHz 1 to 4 Watts Front 14 Character/15 Button
H01SDD9AA4_N 48 450-520 MHz 1 to 4 Watts Top 6 Character/None
H01SDH9AA7_N 160 450-520 MHz 1 to 4 Watts Front 14 Character/15 Button
800 Models H01UCD6AA4_N 48 806-870 MHz 3 Watts Top 6 Character/None
H01UCD6AA7_N 160 806-870 MHz 3 Watts Front 14 Character/15 Button
Power Supply: Provided through one rechargeable nickel cadmium battery.
Sealing: Withstands rain testing per Mil. Std. 810 C/D/E
Shock and Vibration: Protection provided via impact resistant housing exceeding EIA RS-316B and Mil. Std. 810 C/D/E
Dust and Humidity: Protection provided via weather resistant housing exceeding EIA RS-316B and Mil. Std. 810 C/D/E
MT 2000
Synthesized FM Portable Radio
SPECIFICATIONS
TYPICAL PERFORMANCE SPECIFICATIONS*
SUPPORT SERVICES
Wherever Motorola sells, our product
is backed by service. Our products
are serviced throughout the world by
a wide network of company or
authorized independent distributor
service organizations.
SERVICE
Communications
CUSTOMER
R3-4-150C
Specifications subject to change without notice.
Motorola U.S.A. Motorola Canada Limited
1301 E. Algonquin Road 3900 Victoria Park Avenue
Schaumburg, Illinois 60196 North York, Ontario M2H 3H7
In the U.S. call: 1-800-247-2346 In Canada call: 1-800-268-5758
Outside the U.S. and Canada call: (847) 538-6602
, Motorola, MT 2000, Channel Scan, Private-Line, Digital Private-Line, Quik-Call, Stat-Alert,
and Touch-Code are trademarks of Motorola. ■ © 1996 by Motorola Inc. ■ Printed in U.S.A.
■ (9804) Merit ■ Produced by Customer Communications.
Motorola is an Equal Employment Opportunity/Affirmative Action Employer
Radio Dimensions Radio Weight A4 A7
Radio Only: 6.30˝ (H) x 2.34˝ (W) x 1.49˝ (D) Radio Only: 10.3 oz. 10.9 oz.
With Medium Capacity Battery: 6.30˝ (H) x 2.34˝ (W) x 1.49˝ (D) With Medium Capacity Battery: 17.0 oz. 17.6 oz.
With High Capacity Battery: 6.30˝ (H) x 2.34˝ (W) x 1.49˝ (D) With High Capacity Battery: 18.4 oz. 19.0 oz.
With Ultra High Capacity Battery: 6.30˝ (H) x 2.34˝ (W) x 1.54˝ (D) With Ultra High Capacity Battery: 19.5 oz. 20.1 oz.
Dimensions Note: All depth and width dimensions reflect measurements taken at the widest points on the radio unit. They do not reflect every width and depth point on the radio.
Battery Life @ 5/5/90 VHF @ 5W VHF @ 1W UHF @ 4W UHF @ 1W 800 @ 3W
Medium Capacity Battery: 4.0 Hours 5.0 Hours 4.0 Hours 5.0 Hours 3.6 Hours
High Capacity Battery: 8.0 Hours 11.0 Hours 8.0 Hours 11.0 Hours 8.0 Hours
Ultra High Capacity Battery: 9.0 Hours 12.0 Hours 9.0 Hours 12.0 Hours 9.0 Hours
TRANSMITTER
Frequency Range: 136-174 MHz 403-470 MHz 450-520 MHz 806-825 MHz
851-870 MHz
Channel Spacing: 12.5/25/30 kHz 12.5/25 kHz 12.5/25 kHz 25 kHz
Modulation Acceptance
@ 12.5 kHz: ± 3.75 kHz ± 3.75 kHz ± 3.75 kHz
@ 25 or 30 kHz ± 7.5 kHz ± 7.5 kHz ± 7.5 kHz ± 7.5 kHz
Audio Distortion: 3% 3% 3% 3%
Intermodulation
@ 12.5 kHz: –65 dB –63 dB –63 dB
@ 25 or 30 kHz –75 dB –73 dB –73 dB –70 dB
Sensitivity:
20 dB Quieting: .40 µV .40 µV .40 µV .50 µV
12 dB Sinad: .28 µV .28 µV .28 µV .35 µV
Adjacent Channel Selectivity
(12 dB Sinad):
@ 12.5 kHz: –65 dB –63 dB –63 dB
@ 25 or 30 kHz: –75 dB –73 dB –73 dB –70 dB
Spurious Response Rejection: –75dB –73 dB –73 dB –70 dB
1
⁄2 I.F.: –75dB –68 dB –68 dB –70 dB
Image Rejection: –74dB –73 dB –73 dB –74 dB
Rated Audio Output: 500 mW 500 mW 500 mW 500 mW
Frequency Stability:
@ 12.5 kHz: ± .0005% ± .0003% ± .0003%
@ 25 or 30 kHz: ± .0005% ± .0005% ± .0005% ± .00025%
(–30 to +60º C; 25º C ref.)
RECEIVER
*
Specifications are per EIA 316B unless otherwise noted.
