9-8 Keypad Circuit Board/Schematic Diagrams and Parts List
Keypad Board Parts List (5000 and 7000
Series)
Circuit Ref.
Motorola Part
No.
Description
B501 0986237A02 Battery Contact
Module
B503 3980502Z01 Backup battery B+
B504 3980501Z01 Backup battery B-
C610 2113743N50 100 pF
C613 2113743N50 100 pF
C615 2113743N50 100 pF
C616 2113743N50 100 pF
D601 4880479U01 79U01
D602 4880479U01 79U01
D603 4880479U01 79U01
D604 4880479U01 79U01
D605 4880479U01 79U01
D606 4880479U01 79U01
J601 0980521Z01 44 pin connector
J602 0905505Y03 18 pin connector
Q601 4805128M67 MMBT3906
transistor (PNP)
Q602 4880214G02 MMBT3904
transistor (NPN)
Q603 4880214G02 MMBT3904
transistor (NPN)
R601 0662057V20 51K
R602 0662057V20 51K
R603 0662057V05 13K
R604 0662057V11 22K
R605 0662057V18 43K
R606 0662057V30 130K
R607 0662057V05 13K
R608 0662057V11 22K
R609 0662057V18 43K
R610 0662057V30 130K
R611 0662057N16 51K
R612 0662057N41 560K
R613 0662057N47 1M
R614 0662057M01 0 ohm
R617 0662057M01 0 ohm
R618 0662057M74 1K
R619 0662057M74 1K
R620 0662057M74 1K
R621 0662057M74 1K
R622 0662057M74 1K
R623 0662057M74 1K
R626 0662057M01 0 ohm
R627 0662057M01 0 ohm
R631 0662057M01 0 ohm
R632 0662057N23 100K
R633 0662057N23 100K
R634 0662057M01 0 ohm
R637 0662057M01 0 ohm
R638 0662057M01 0 ohm
R639 0662057M01 0 ohm
R640 0662057M01 0 ohm
R641 0662057M01 0 ohm
R642 0662057M01 0 ohm
R643 0662057M01 0 ohm
R644 0662057M01 0 ohm
R645 0662057M01 0 ohm
R646 0662057N23 100K
R647 0662057M85 3K
R648 0662057N23 100K
R649 0662057N15 47K
U602 5102463J49 LMC7211
comparator
Circuit Ref.
Motorola Part
No.
Description
