RADIO OVERVIEW
English
21
Installing Spring Action Belt Clip
1. Slide the spring action belt clip rails into the belt
clip grooves on the back of the battery pack and
slide it down until the belt clip tab snaps into
place.
2. To remove, pull back the metal release tab on
the belt clip tab and push the spring action belt
clip upward to remove.
Power Supply, Adaptor and Drop-in Tray
Charger
The radio is equipped with one Drop-in Tray
Charger and one Power Supply with Adaptor.
For details, see “Chargers” on page 86.
Belt Clip
Tab
Spring
Action Belt
Clip
Drop-in Tray Charger
Power Supply
BRUS_display.book Page 21 Monday, January 16, 2012 5:28 PM
