RADIO LED INDICATORS
RADIO STATUS LED INDICATION
Channel Alias Edit Red heartbeat
Channel Busy Solid orange
Cloning Mode Two orange heartbeats
Cloning In Progress Solid orange
Fatal Error at Power up
One green blink, one orange blink, one green blink, then repeat for 4
seconds
Low Battery Orange blink
Low Battery Shutdown Orange heartbeat
Monitor LED is OFF
Power-Up Solid red for 2 seconds
‘Idle’ Programming Mode /
Channel Mode
Green heartbeat
Scan Mode Red heartbeat
Transmit (Tx)/Receive (RX) Red heartbeat
Transmit in Low Power Select Orange heartbeat
Note: Channel Alias Edit only applies to Display Models
