Motoworks 49cc - Clutch Replacement Guide

To Previous Page

Model: 49cc ATV with Electric Starter



**It’snotrequiredtotakewholeengineoffbike,youcan

leavetheengineonthebikewhilechangingtheclutch**



1. Locatethose4boltsontheclutchsideofengine.

2. Removethose4boltsandremovetheclutchhousing



1. Usethespanner/Ratchettoremovethecentershaftbolt

2. Youmayconsideruseascrewdrivertoloc ktheclutchto

preventit’smovement.



Afteryousuccessfullycompleteupsteps.

 Youshallhavealon g shaftboltandcenterwasherout.



Beforeweactuallytouchtheclutchitself.

1. !!!Leavethewasheraside!!!

2. Puttheshaftboltback

**Weneedusetheshaftbolttokeeptheunderneath

magnetoplateontheshaft,topreventtake wholestarter

systemoutwhileremovingtheclutch**



1. Useascrewdrivertrytota ketheclutch

!!!PleaseMakeSuretheWasherhasbeenputaside!!!



Congratulation!!NowwecanfinishedClutchchange.

1. PutNewClutchOn

2. KnockClutchwithhammer,makeitfittheshaft.Begentle

3. Putthewasherandcenterlon g shaftboltback

4. Pulltheclutchhousingback,pleasedo u b le checkthe

directionthenputthose4boltsback.
