BODY COVER
12-3
Seat
hold-all
FLOOR PANEL
Frame
fender/Front fender
Front fender back
MAINTENANCE INFORMATION
Body covers disassemble sequence:
Be careful not to damage various covers in disassembly or re-assembly operation.
Never injure hooks molded on the body covers in disassembly or re-assembly
operation.
Align the buckles on the guards with slot on the covers.
Make sure that each hook is properly installed during the assembly.
Never compact forcefully or hammer the guard and the covers during assembly.
Rear handle cover
Front panel
Front handle cover
Decorative pieces on the
front panel
Glove box
Front fender back
Tool box connector
Glove box cover
BODY COVER
Rear carrier
