12
DESCRIPTION OF THE APPLIANCE
A Large pusher
B Small pusher
C Reducer for small pusher
D Feed tube
E Cover
F Sieve
G Juice collector
H Pouring spout
I Pulp collector
J Clamp
K Switch
L Drive shaft
M Motor unit
N Cord-tidy
O Brush
BEFORE USE
We recommend that you wash the removable parts (parts A, B, C, E, F, G & I) after unpacking the applian-
ce (see chapter CLEANING AND CARE).
Unpack the appliance and then place it on a solid , stable work surface, slip back the clamp (J), remove the
reducer for the small pusher (C), the cover (E), take out the protective card on the sieve (F) then remove
the sieve (F) and the juice collector (G).
STARTING
Fit the pulp collector (I) on the rear of the appliance, tipping it forward slightly to
slide the collector under the safety device.
Fit the juice collector (G) in the appliance, tipping it slightly forward to pass the
pouring spout (H) through the hole provided.
Place the sieve (F) in the juice collector (G). Ensure that the sieve is correctly
clipped onto the drive shaft (L) (audible click).
Fit the cover on the juice collector (E) on the juice collector (G), ejection spout
to the rear.
AUSTIN n°3 27/04/06 15:40 Page 12
