Attaching the Frame to the Desktop
Step 3
9
N
f
Option A: Long side of
desk on the right hand side
Turn the leg frames over and carefully place it upside down on the
desktop. Place the Leg Sections on the Desktop, then connect the
Leg Sections together, using the Frame Joint (#N, O) and using
Bolts (#a) and tighten until secure using the 5mm Hex Wrench (#f).
Align the holes on the Frame with the holes on the Desktop.
Attach the Desk Frame to the Desktop using Screws (#d). Tighten until secure.
f
a
a
d
O
O
N
To Next Page
