Adjustments
(Tilting)
(Leveling)
Tilting angle adjustment (+3° / -12°)
Loosen tilting nuts, pull TV to your
desired angle, then fasten tilting nuts
with open end wrench .
Loosen
Tighten
Tighten
Loosen
±3°
TV leveling adjustment (-3°/+3°)：
Loosen 2 leveling bolts on the rear of TV
plate with the open end wrench ,
adjust to level, and retighten to secure.
C
C
