Mountup MU0012-24K - Page 10

3-4
P1
P2
Hang 02 onto 01 and using a screwdriver to secure with preassembled screws
and washer .
P1
P3
P3
Remove the
preassembled
screws [P3] and
save to use, then
raise the safety
locks.
Press the safety locks
then fasten the removed
screws [P3].
01
02
03
STEP 4 Hang TV with Brackets onto the Arm Extensions
04
02
03
P2
- 10 -
02 01
P3
P3
